Description
The new Genesis Sport mini is based on the proven design of the Raw 420 competition. Sharing the same mechanics, transmission, head and tail, the Genesis Sport "mini" offers better visibility making it ideal for those who prefer an easier to see, sport flying or mild 3D flying machine.
This helicopter can run on any motor size ranging from 2820 to 3220 and KVs ranging from 800 to 1000. With motor pulley options, you now have the ability to fine tune your head speed based on your motor of choice.
This helicopter is a breeze to build. It has a very low parts count and has many other features like an improved tail push rod, an integrated flybarless system antenna mount and more.
Designed to run on 6s packs ranging from 2200-2700 mAh and comes with main and tail blades. You simply need to get a motor, servos (micro cyclic & mini tail), an ESC and a flybarless controller! We recommend either the HobbyWing 60 or 80 amp speed controllers or the Scorpion 06 80A esc. All of these are excellent choices if you are planing on doing mild 3D or sport flying. For harder 3D, the 80 amp HW ESCs are preferred.
- Main rotor diameter 935mm (with 420mm blades)
- Main blade length 380 to 420mm
- Tail rotor diameter 190mm (with 70mm tail blades)
- Tail blade length 60 to 70mm
- Micro size cyclic servos (23mm)
- Mini size tail servo (35mm)
- Maximum battery size: 140x40x50mm (max)
- Recommended battery: 6s 2200/2700 mAh
- Recommended motor: 3020 – 3215 – 3220
- Recommended KV motor: 900-1000 KV
- Recommended battery weight: 350-420 grams
- Recommended ESC: 60 (70-80A is required only for hard 3D flight with temperatures above 30°C)
- Tail rotor ratio 4:1
- 8mm main shaft
- 5mm tail shaft
Main Features:
- Quick release battery tray with integrated connectors
- Zytel HTN resin blade grip arms (sacrificial)
- It is not necessary to remove the canopy to replace the batteries.
- Main ratio 1:5/6
- Tail ratio 4:1
